Picosecond Laser Tattoo & Pigmentation Removal Machine,K690

A professional picosecond laser system featuring 532 nm, 755 nm, and 1064 nm wavelengths, with optional 585 nm and 650 nm configurations. Equipped with a 7-joint articulated arm and a 15.6-inch touchscreen, it is designed for tattoo removal and pigmentation treatments.



Custom-built for Professional Medical Aesthetic Clinics

Picosecond Laser Tattoo Removal Machine


A professional picosecond laser system for aesthetic clinics, dermatology centers, and beauty institutions, featuring multi-wavelength technology for tattoo removal, pigmentation treatment, and skin rejuvenation

Multi-Wavelength System

3000W High Power

Picosecond Precision

picosecond laser tattoo removal machine 2

Core Technical Advantages of Picosecond Laser

High-Tech Performance
Honeycomb Focus technology delivers precise treatment and protects surrounding skin.
Fast & Effective Results
Shortens treatment cycles and recovery time for visible outcomes.
Safe & Comfortable Treatment
Precise targeting reduces skin damage during pigment removal.
Reduced Melanin Deposition
Ultra-short pulses shatter pigments into fine particles for easy metabolism.

pico laser tattoo removal machine
professional picosecond laser tattoo removal machine

One Lamp Two Rods System: Advanced Picosecond Laser Technology

Laser Technology
Ultra-Short Pulse Technology
Delivers high-energy pulses for precise pigment targeting.
Photoacoustic Fragmentation
Breaks pigments into fine particles for efficient clearance.
Low Thermal Damage
Reduces heat accumulation for safer, more comfortable treatments.
Honeycomb Focus Effect
Creates controlled micro-effects for precise skin treatment.

Multi-Wavelength Laser System for Advanced Skin Therapy

1064nm Laser
Deep pigment targeting for dark tattoos and deeper pigmentation.
755nm Laser
High melanin absorption for pigmentation treatment and skin brightening.
532nm Laser
Targets superficial pigments and colored tattoo removal.
Optional Dye Laser
585nm for vascular treatments | 650nm for green tattoo removal.

picosecond tattoo removal laser
medical grade pico laser tattoo removal machine

Advanced 7-Joint Korean Imported Arm System

360° Flexible Rotation
Enables precise positioning and easy access to different treatment areas.
Stable Laser Transmission
Minimizes energy loss and ensures consistent laser output.
Enhanced Clinical Efficiency
Flexible arm movement improves operator control and treatment efficiency.
Multiple Treatment Heads
Supports various interchangeable handpieces for customized treatments across different applications.

Multi-Wavelength Picosecond Laser Treatment Applications

755nm Laser
Honeycomb technology targets melanin for effective pigmentation treatment.
1064nm Laser
Deep pigment targeting for tattoos, eyebrow, lip, eye line tattoos, and deeper pigmentation.
532nm Laser
Superficial pigment treatment for freckles, coffee spots, and colored tattoos.
585nm Dye Laser
Vascular treatment and facial redness reduction.
650nm Dye Laser
Green tattoo removal.
Focus Array Lens
Supports acne scar improvement, wrinkle reduction, and skin rejuvenation by stimulating collagen production.

picosecond laser tattoo removal machine for clinic

K690 is suitable for:Medical spas,Beauty salons,Dermatology clinics,Aesthetic clinics,Laser hair removal centers,Professional distributors.

Picosecond Laser Tattoo Removal Machine

This laser device can perform treatments on the face, chest/decollete, hands, legs, eyebrow area, lip area, eyeliner area, and other tattoo areas across the body.

Why Choose KEYLASER for Diode Laser Equipment?

Core Advantages
19+ Years Manufacturing Experience as a professional Diode Laser Hair Removal Equipment Supplier
Factory Direct Supply
OEM / ODM Customization Available
Global Distributor Support
7×24-Hour Technical Support
Full Certifications: FDA 510(k), CE MDR, MDSAP, ISO 13485

Picosecond Laser Tattoo Removal Machine - Product Specifications
Operation Interface 11.6” TFT True Color LCD Screen
Laser Type Picosecond
Wavelength 1064nm 755nm 532nm (585nm 650nm Focus Array Lens optional)
Pulse Energy 532nm: 50-1000mj
755/1064nm: 100-2000mj
Power 3000W
Frequency 1-10HZ
Width of pulses 550-750ps
Laser Rod 6mm+7mm
Diameter of Spots 2-10mm adjustable
Beam of Light Transmission 7 articular-arm of light guide transmitting
Indicator of Aiming Light Red light 650nm
Cooling Manner Closed-off water circulation + air
Net Weight 90kg
Q:What makes picosecond laser different from traditional laser systems?

A: Picosecond laser uses ultra‑short pulses to create stronger pigment fragmentation with less thermal accumulation.

A: K690 supports 1064nm, 755nm, and 532nm wavelengths, with optional 585nm and 650nm dye laser modules.

A: Yes. Its high‑power output, multi‑wavelength configuration, and stable delivery system are designed for professional aesthetic clinics.

A: The system integrates precise targeting technology, dual‑mode cooling system, key switch, and emergency switch functions.

A:Yes. With different wavelengths and treatment heads, K690 supports tattoo removal, pigmentation treatment, skin rejuvenation, and scar improvement.
